HD-C LT, Low Temperature

Antarctica: Low Temperature aircraft refuelling hoses in action

Production plastic precision parts

Elaflex Hamburg

Assembling cell dispensing hoses

SVX 50-2"

Male hose coupling of steel with Spannfix clamps

Elaflex Hamburg

Elaflex stock

Lightweight Gravity Discharge Road Tanker Hose LG 3"

with VX 75-3" Al LG

Oasis HC308 Ultra Fast Quick Fill Coupler, SAE male, for CNG

ROTEX Rubber Expansion Joints

Biomass powerplant

Storz coupling; water connector ship

Underwing refuelling, HD-C hose assembly

Aircraft refuelling:

Yellow Band quality hoses

ELAPAC FD flat sealing material

2 or 3 mm thickness, available as coil, standard size seal or in custom shape. An elastic flange seal for tank truck and tank plant construction etc., where rough sealing surfaces require a high adaptability, where flange seals should still have good flexibility to avoid pipe fractures or simple sealing materials because little or no force can be used to tighten the joint.

CBC-C

Cryogenic Breakaway Coupling for LNG with cable release:
before release

ELAPHARM Type EPH

electrically isolating 'I', with blue cover, to EN 16820, Type A. FDA conform, homogeneous elastomer hose construction with smooth, white PTFE liner. Clamp fittings, lining flared (free of dead spaces).

Oasis BV706 ball valves with Code 62 flange connection, for CNG

ZVA Slimline 2 / ZVA Slimline 2 GR

Petrol station nozzles with and without vapour recovery, hose assemblies

Solvent filling with integrated vapour recovery in the nozzle

ZVA 25 GR, UTS hose assemblies

Elaflex hoses

HD, TW, LPG, FXD, SL, FEP, CHS, LMS, UTS, PTFE, PCS

ZV 19.1 TD

ZV 19 manually operated dispensing nozzle, DN 19 ( 3/4" ), up to 100 ltr./min. Special version for chemicals/solvents with PTFE seals.

ZVG 2 ACME / EURO / DISH

Nozzles for L.P. Gas (Autogas) refuelling

Anti-Kinking Spirals 'KSS' and 'KSS-SD'

The main bending stress area for hose assemblies is directly behind the coupling. To reinforce this area we developed the Anti- Kinking Spiral 'KSS': suitable for all ELAFLEX hoses, recommended for dynamically strong stressed universal hoses with thermoplastic linings

Petrol station in Dubai

ZVA Slimline 2 nozzle, SSB 16 Safety Break, Slimline hose assembly

Unloading chemical road tanker

Solvapal hose assembly with DDC Dry Disconnect Couplings

Cargo loading of a tanker with petroleum based products; FHD hose assembly with new longitudinal stripe to avoid torsion

Picture courtesy of Macoil International, Gibraltar

Terminal / gantry: 'Polypal Oil' hose assemblies for bottom loading of road tankers

Lining UPE - resistant to all petrochemical media, also with high content of aromatics or other aggressive additives; cover CR - oil resistant

Tank container, Antarctica: HD-LT hose assembly, ZVF 25 LT nozzle

Low Temperature types

Upstream Oil Industry, TW hose assemblies

Kuwait

GasGuard LPG nozzle GG1E

eoconomic type for industrial refueling / attended refueling. Release volume on valve closure : 1,9 cm³.

Boat refuelling Australia

ZVA Slimline 2, Slimline hose assembly

FFC 50.16 St

Fixed flange hose fitting of steel, with Spannloc clamps
